INFRASTRUCTURE (MACHINE DETAILS)
CNC TURRET PUNCHING MACHINE
MAKE: FINN POWER (PRIMA POWER)
MODEL: C5 (30 M.T.)
CAPACITY: 2500 x 1250 x 8 mm thick
TOOLING: MATE (USA)
KEY FEATURES: Brush table, automatic clamping, programmable clamp switching, forming, marking & all advanced features.
CNC FIBRE LASER CUTTING MACHINE
MAKE: SIL
MODEL: 3015 – ECAT WITH ENCLOSED BODY & DUEL PALLET CHANGER
BED SIZE: 3050 X 1525 MM
POSITIONING ACCURACY: 0.03MM
CUTTING CAPACITY: 20 MM MS / 12 MM SS / 8 MM ALUMINIUM
CNC SYNCHRONIZE HYDRAULIC PRESS BRAKE MACHINE(BENDING)
MAKE: PURVAJ
MODEL: CSHPB 30100 (5 - AXIS)
CAPACITY: 100 TON X 3000 MM ( 3000 MM X 4 MM THICK)
KEY FEATURES: TOUCHSCREEN CONTROLLER WITH GRAPHICS , QUICK RELEASE CLAMP , SPECIAL TOOLING FOR CRITICAL BEND SECTIONS.
CNC SYNCHRONIZE HYDRAULIC PRESS BRAKE MACHINE(BENDING)
MAKE: PURVAJ
MODEL: CSHPB 1530 (3 – AXIS)
CAPACITY: 30 TON X 2500 MM ( 1500 MM X 2.5 MM THICK)
KEY FEATURES: TOUCHSCREEN CONTROLLER WITH GRAPHICS , QUICK RELEASE CLAMP , SPECIAL TOOLING FOR CRITICAL BEND SECTIONS.
CNC PU FOAM GASKET MACHINE
MAKE: HGIT
MODEL: HGTJ401 (WITH BECKHOFF GERMAN DISPENSING SYSTEM)
CAPACITY: GASKET WIDTH 8 MM TO 30 MM.
X Y Z SIZE: 2200MM X 1200MM X 190MM
KEY FEATURES:BECKHOFF TOUCHSCREEN CONTROLLER WITH GRAPHICS, HIGH SPEED PROCESSING UPTO 500 MM/SEC, AUTOMATIC THREE DIMENTIONAL INTERPOLATION
NC SHEARING/CUTTING MACHINE
MAKE: BHAVYA
MODEL: NCS-4x2500
CAPACITY: 2500 x 4 MM
KEY FEATURES: ESTUN E21S LCD CONTROLLER, INTELLIGENT POSITIONING OF BACK GAUGE, AUTOMATED SHEAR ANGLE ADJUSTMENT, PRORAMME MEMORY.
VERTICAL MACHINING CENTRE
MAKE: MORI SEIKI
MODEL: MV 55/50
TABLE SIZE: 1400 X 550
Travels X, Y, Z: 1050 X 550 X 550
WELDING MACHINES
MIG WELDING : 5 NOS
HD PULSE TIG WELDING : 1 NO.
ACDC TIG WELDING: 1 NO.
STUD WELDING: 1 NO.
OTHER MAJOR EQUIPMENTS & INSRUMENTS:
1) 200 KVA OIL COOLED SERVO STABILIZER FOR COMPLETE FACTORY.
2) 60 KVA UPS WITH ONE HOUR BACK UP FOR LASER MACHINE.
3) 10 KVA UPS WITH ONE HOUR BACK UP FOR PU GASKET MACHINE.
4) COMPRESSOR FOR LASER 16 BAR – 1NO
5) COMPRESSOR FOR PUNCHING 7 BAR – 1 NO
6) RADIAL DRILL MACHINE – 1 NO
7) HAND DRILL MACHINES – 2 NOS
8) GRINDERS & SANDERS – 8 NOS
9) POLOISHING/BUFFING MACHINE – 1 NO
10) ASSEMBLY TOOL SET – 10 SETS
11) VERNIER/MICROMETER/DIAL GUAGE ETC – 1 SET
Excellence in Engineering, Precision in Manufacturing
